Lochinvar & A.O. Smith 100111017 Display Board
When service calls demand a precise UI restoration for high-efficiency commercial water heaters, the Lochinvar & A.O. Smith 100111017 Display Board is the definitive OEM solution. Engineering standards have evolved, making the 100111017 user interface module the official 9006240005 replacement board for modernizing older control stacks. This commercial water heater display provides critical real-time diagnostic feedback and system configuration for A.O. Smith Cyclone Xi and Lochinvar Armor water heater series. Designed for high-amperage, high-duty cycle environments, this digital control interface ensures seamless communication between the main controller and the technician, allowing for exact parameter adjustments and error code clearing. In the field, using a genuine OEM display board is the only way to ensure full firmware compatibility with existing BTH, SUF, and HCG burner controls. Relying on this updated 100111017 module prevents the "sync" failures common with older or secondary-market revisions, keeping critical hot water systems online and fully optimized.
Key Benefits for Contractors- Direct OEM Compatibility: Engineered as the primary 9006240005 replacement board for A.O. Smith and Lochinvar commercial units.
- Enhanced Diagnostics: Provides clear, high-contrast visual output for rapid troubleshooting of combustion and flow errors.
- Firmware Integration: Supports the latest operational protocols for Cyclone BTH and Armor series models (120-500 series).
- Rugged Design: Built to withstand the humidity and ambient heat levels typically found in high-output mechanical rooms.
- Can I use this board for a residential unit? No, the 100111017 display board is specifically calibrated for commercial gas water heater configurations like the BTH and GDHE series.
- My old board number is 9006240005. Is this the right part? Yes, the 100111017 is the direct superceding part number for the 9006240005.
- Why does my new display say "Not Synced"? Ensure the communication ribbon cable is seated correctly and that the unitās serial number falls within the supported range for this specific user interface module.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
