Honeywell Q314A6102 Pilot Burner
The Honeywell Q314A6102 Pilot Burner is a professional-grade, non-primary aerated standing pilot assembly designed to provide reliable main burner ignition in both residential and commercial gas-fired equipment. This insert orifice type pilot burner is engineered for maximum field flexibility, featuring a Type B mounting bracket and a single target tip style (K-tip) with a right-hand flame direction. It is a drop-in HVAC replacement part for obsolete models including Q314A3729, Q314A4024, and Q314A4834. Designed for natural gas and liquid propane systems, the assembly includes both a .018" orifice (BCR-18) and a .010" orifice (BBR-10). The 1/4" compression fitting ensures a secure connection, while the included conversion kit allows contractors to adapt the "B" bracket to an "A" bracket configuration seamlessly. For optimal performance, this Honeywell pilot light assembly is fully compatible with Q309, Q340, and Q390 thermocouples or Q313 thermopiles, ensuring consistent millivolt generation for your safety circuits.
Key Benefits- Multi-Fuel Compatibility: Shipped as a complete kit for LP and Natural Gas applications with color-coded interchangeable orifices.
- Direct OEM Replacement: Replaces multiple legacy Honeywell pilot burners, streamlining inventory for service technicians.
- Universal Mounting: Includes a specialty bracket and screws to convert from a standard "B" bracket to an "A" bracket in the field.
- Reliable Ignition: Non-primary aerated design reduces the risk of linting and pilot outages in standing pilot systems.
Is the Honeywell Q314A6102 compatible with my thermocouple?
Yes, this assembly is designed to work with standard Honeywell thermocouples such as the Q340A and Q390A, as well as Q313 thermopiles for powerpile systems.
What is the direction of the flame on this pilot burner?
The Q314A6102 features a right-hand (K-style) tip direction, which is critical for proper alignment with the main burner port in specific furnace and boiler configurations.
Can I use this to replace a Q314A6102/U?
Yes, the Q314A6102 and the "U" (Universal/Tradeline) suffix version are functionally identical and serve as direct replacements for one another.
Disclaimer: While we strive for 100% accuracy, product data and specifications are subject to change. Please contact our team to confirm compatibility or technical details before purchasing.
